CU-NI 90-10 PIPES

Products We Offer

CU-NI 90-10 PIPES

CU-NI 90-10 PIPES

Copper Nickel 90/10 Tube Price

Size Price in USD Price in INR
9.52MM OD X 0.9MM THK $ 37.77 3147.99
40 MM OD X 1.65 MM WT (AVG.) X 4103.00 MM $ 12.42 1035.16
0.75 OD X 0.049 WT X 2 INCH LENGTH $ 57.32 4777.41
0.625 OD X 0.049 WTX 6 INCH LENCTH $ 57.95 4829.92
1.00 OD x 0.049 WT X 2 INCH LENGTH $ 91.69 7642.02
0.50 OD X0.049 WT X INCH LENGTH $ 46.46 3872.27
5/8 OD X 16 BWG – 2440MM LONG $ 42.98 3582.22
0.50 ODX 0.049 WT X 2 INCH LENGTH $ 42.43 3536.38



Well-known Supplier of ASME SB 466 90 10 Cuni Pipe in Mumbai in Maximum Sizes, Refer to the Wnr 2.0872 Tubing Size Chart

Size Chart Of ASTM B466 C70600 Seamless Pipe

Size (in) Wall Thickness (in) Outside Diameter (in)
1/4 OD 0.049 0.25
1/4 OD 0.035 0.25
1/2 OD 0.035 0.5
3/8 OD 0.035 0.38
3/4 OD 0.049 0.75
5/8 OD 0.049 0.62
3/4 OD 0.06 0.75
3/8 0.065 0.68
1/4 0.065 0.54
1/2 0.065 0.84
1 0.065 1.32
3/4 0.065 1.05
1-1/4 0.072 1.66
2 0.083 2.38
1-1/2 0.072 1.9
3 0.095 3.5
2-1/2 0.083 2.88
20 0.25 20
3-1/2 0.095 4
5 0.125 5.56
4 0.109 4.5
6 0.134 6.62
10 0.187 10.75
8 0.148 8.62
12 0.25 12.75
16 0.25 16
14 0.25 14
18 0.25 18
24 0.25 24



Find ASTM B467 90 10 Copper Nickel Welded Pipe With Prompt Shipment and Excellent Customer Service to Fulfil Your Needs, Check EEMUA 144 Pipe Specification

90 10 Cuni Pipe Specification

Copper Nickel 90/10 Tube Manufacturer in India in Maximum Sizes

OD

Outside Diameter

1/2 to 6 "

Cupro Nickel 70/30 Tubes Thickness

Cupro Nickel 70/30 Tubes Thickness

0.15 and 1.50 mm

Copper Nickel 70/30 Pipes Length

Copper Nickel 70/30 Pipes Length

Single Random, Double Random & Required Length



Schedule

Schedule

SCH30, STD, SCH40, SCH20, XS, SCH80, SCH80, SCH60, SCH140, XXS, SCH120, SCH160

Type

Type

Welded / ERW /Seamless / Fabricated

70/30 Copper Nickel Seamless Tubes Method

70/30 Copper Nickel Seamless Tubes Method

Cold Rolled / Hot Rolled



Standards

Standards

ASTM B466, B467, B111, B552, B543, B395/ ASME SB466, SB467, SB111, SB552, SB543, SB395

Forms

Forms

Square, Round, Hydraulic, Rectangular, Coil, ‘U’ Shape, Pan Cake

Copper Nickel 70/30 Pipe Finish

Copper Nickel 70/30 Pipe Finish

Cold Finish, Bright, Annealing, Pickling, Polished



Testing

Testing

Chemical, PMI, Mechanical, Visual Inspection, NABL Approved Lab Reports

End

End

Plain End, Beveled End, Threaded

Copper Nickel 70/30 Tube Uses

Copper Nickel 70/30 Tube Uses

Heat Exchanger, Brake Lines, Distiller Tube, Condensers, Evaporator Tube



Applicable Specfication

End Product Specification
Welded Pipe ASTM B467, B608, ASME SB467
Seamless Pipe ASTM B466, ASME SB466
Condenser Tube ASTM B111, B552, ASME SB111, SAE J461, J463, MILITARY MIL-T-15005
Related Specifications
  • CW352H
  • C70600
  • CN102
  • C70610
  • DEF STAN 02-779
  • DEF STAN 02-879 Annex C
  • BS2874
  • NES 779
  • EN 12163
  • BS2870
  • NF A51-115
  • ASTM B151
  • CuNi10Fe1Mn
  • 2.0872



Provide a Broad Range of ASTM B543 Copper Nickel 90/10 Welded Tube in a Bespoke Shape and Size With Prompt Delivery, See EEMUA 234 Pipes Weight Chart

Weight Chart Of 90 10 Copper Nickel Welded Pipe

N.P.S. Wght In KG Wall Thk. O.D. SCH Wght IN LBS
Kilogram/ Meter Inch. Millimeter Inch. Millimeter LBS/ Foot
3/4″ 1.684 0.113 2.870 1.050 27 40 STD 1.131
  2.195 0.154 3.912     80 STD 1.474
1/2″ 1.268 0.109 2.769 0.840 21 40 STD 0.851
  1.621 0.147 3.734     80 STD 1.088
1 1/4″ 3.385 0.140 3.556 1.660 42 40 STD 2.273
  4.464 0.191 4.851     80 STD 2.997
1″ 2.501 0.133 3.378 1.315 33 40 STD 1.679
  3.325 0.179 4.547     80 STD 2.172
2″ 5.441 0.154 3.912 2.375 60 40 STD 3.653
  7.480 0.218 5.537     80 STD 5.022
1 1/2″ 4.048 0.145 3.683 1.900 48 40 STD 2.718
  5.409 0.200 5.080     80 STD 3.361
3″ 11.284 0.216 5.486 3.500 89 40 STD 7.576
  15.272 0.300 7.620     80 STD 10.253
2 1/2″ 8.629 0.203 5.516 2.875 73 40 STD 5.793
  11.411 0.276 7.010     80 STD 7.661
6″ 19.252 0.188 4.775 6.625 168   12.924
  20.739 0.203 5.516       13.923
  22.318 0.219 5.563       14.983
  25.354 0.250 6.350       17.021
4″ 16.073 0.237 6.020 4.500 114   10.790
  22.318 0.337 8.560       14.983



About CU-Ni 90-10 Pipes




Experience the extraordinary reliability of CU-Ni 90-10 Pipes, acclaimed for their inestimable strength and grand corrosion resistance, particularly in seawater environments. These seamless and welded pipes are designed for excellence, boasting a density of 8.94 g/cm3, tensile strength of 245-335 MPa, and an elongation of 30% min. With tailored tolerance, connection, and surface finish options, each pipe stands out for its customizability, durability, and versatility. Add to Cart or Get It Now to secure these industry-leading pipes-ideal for marine, offshore, and industrial projects!

Exceptional Applications and Use Cases

CU-Ni 90-10 Pipes are predominantly used in marine, shipbuilding, offshore, desalination, and industrial heat exchanger settings. Their application method includes both straight and coiled forms, suitable for a variety of installation types and connection styles, such as plain, beveled, or threaded ends. These pipes are used where unparalleled corrosion resistance and mechanical stability are essential, ensuring lasting performance in demanding environments. Usage type ranges from new installations to critical replacement projects.


Logistics: Stock, Port, and Payment Options

Our CU-Ni 90-10 Pipes are stock ready for prompt dispatch from major Indian ports. Expect swift arrival with minimal outlay on logistics, ensuring efficient project timelines. We provide flexible sample policies for initial assessments, safeguarding your investment. Standard payment terms accommodate various business needs, making procurement seamless and convenient. Choose from a range of ports and shipment options to suit your requirements effortlessly.




FAQ's of CU-Ni 90-10 Pipes:



Q: How do CU-Ni 90-10 Pipes benefit marine and offshore projects?

A: CU-Ni 90-10 Pipes offer extraordinary corrosion resistance in seawater, high strength, and excellent durability, making them ideal for marine and offshore environments where longevity and reliability are paramount.


Q: What standards and specifications do these pipes adhere to?

A: The pipes comply with ASTM B466/B467, EEMUA 144, and DIN 86019 standards, ensuring premium quality and compatibility across global projects.


Q: Where are CU-Ni 90-10 Pipes commonly used?

A: They are extensively used in shipbuilding, desalination plants, heat exchangers, condensers, and a wide array of marine and industrial applications.


Q: What is the process for ordering and receiving CU-Ni 90-10 Pipes?

A: Simply select your required dimensions and finishes, add to cart, and complete your transaction. Orders are quickly processed and dispatched from available stock for timely arrival.


Q: What are the available end types and surface finishes?

A: These pipes can be supplied with plain, beveled, or threaded ends, and are available in polished, mill finish, bright annealed, or pickled surface treatments.


Q: Can I get custom-cut lengths and different shapes for my project?

A: Yes, pipes are available in custom-cut or standard lengths up to 6 meters, with various shapes such as round, square, or rectangular to match your project requirements.
